System Includes

• Main Unit: 1 set
• Blow Dryer Bracelet: 1
• pc Air gun of soldering station-1 PC
• Screw: 2 pcs.
• Soldering Iron Stand: 1 pc
• Suction Disc: 11 pcs
• Desoldering station Handle: 1pc
• Spring: 3pcs
• Electric Tweezer Handle: 1 pc
• Suction Nozzles: 3pcs
• Desoldering Gun Handle: 1 pc
• Rubber Washer: 3 pcs
• Desoldering Pen Handle: 1 pc
• Desoldering Nozzles: 3 pcs
• Power Cord: 1 pc
• Nozzles: 4 pcs
• Desoldering Gun front plug: 2pcs
• Desoldering Gun O” ring: 6 x 1.5- 2pcs
•  Desoldering Gun O-ring: 2pcs
• Desoldering tube liner: 1pc
• Filter Cotton: 10Pcs
• Spring Pin(Cleaning Pin): 1Pc
• Anti Ironing Mat: 1 pc
•  manual: 1pc



Features

•
• High Accuracy MCU control is employed to synchronously whether the three tool channels can be used independently and synchronously without mutual interface.
• Built in Vacuum generator.
• The whole machine can provide a maximum of 900W power output.
• Stand alone machine can carryout multiple desoldering tasks simultaneously.
• Large screen graphics display screen which can display all kinds of parameter data and messages graphically.
• Automatically identify all kinds of welding tools and load corresponding parameters.
• The software can adjust the temperature automatically which is more accurate and convenient.
• Fault display and alarm functions available.
• Support Communication interface it can access to a computer and complete various settings following the specified program.
• Functions such as stand by buzzer ringing temperature lock and factory reset data available.
• Vacuum desoldering pen added to facilitate dismantle the desoldering components.



Specifications

• Voltage: AC 220V/230V/240V, 50/60Hz Optional
• Total Power:600W
• Display: LCD
• Main Unit:
• Hot Air Station
• Power:Heater :200W
• Pump 25W
• Soldering Station:120W
• Desoldering Station: 120W , Vacuum Pump-25W
• Electronic Tweezers: 120W
• Temperature 50⁰C~450⁰C ( Four Channal )
• Range :
•
• Stand By: No Stand By( hotair)
•                 200⁰C ( sold)
•                 300⁰C ( desold)
•                 200⁰C ( Tweezer)
•
• Stand By Time: 1~120 min
• (0 ie Stand by deactivated )
•
• Air Flow :Grades15L/Min
• Noise:<52DB(A)
•
• Temperature
• Stability:±2⁰C
• Temperature
• Accuracy: ±9°C
•
• Temperature
• Compensation: -50⁰ C ~ +50⁰C
•
• Lock Setting: Available
•
• Tip to ground impedance: <2Ω
• Tip to ground voltage: <2mv
• Overall Dimensions: 310(L) x 251(W) x 119(H)
